The Seakeeper 14 bridges an important gap in the current model lineup between the Seakeeper 10 and the Seakeeper 18 with an innovative design that is 43% smaller and 33% lighter than the Seakeeper 18. Ideal for boats ~55-68 feet.
The next generation of Seakeeper innovations introduces the most efficient and most effective gyrostabilizers ever built.
More stabilization. Smaller Package.
Asymmetric Flywheel
An all-new flywheel design features a deeper lower hemisphere, enabling the motor to be tucked inside the flywheel. This design reduces overall height and provides the most efficient flywheel shape to maximize performance per pound and footprint.
Faster Installation
The new frame can be disassembled to allow for installation in locations where it otherwise may not have fit.
Economical Maintenance
Zinc-nickel plated components, a single-cylinder brake design, and a redesigned cooling system provide better protection and easier maintenance.
Easier Access
Fewer mounting bolts, greater access clearances, and quick-release top cover fasteners make service faster and easier.
| Technical Specifications | |
|---|---|
|
Max Rated Speed |
7,600 RPM |
|
Angular Momentum at Max Rated RPM |
14,000 N-M-S |
|
Spool-up Time to Max Rated RPM |
44 minutes (7,600 RPM) |
|
Spool-up Time to Stabilization |
24 minutes (5,700 RPM) |
|
Power Consumption |
|
|
Spool-Up Power |
3,700 Watts Max |
|
Spool-Up Power Input |
|
|
Operating Power |
1,000 – 3,000 Watts (sea state dependent) |
|
DC Power Input |
|
|
Control Power |
240 Watts Max |
|
Control Power Input |
24 VDC @ 10 Amps Max |
|
Seawater Pump Power Input Over Current Protection based on installed pump rating |
24 VDC @ 10 Amps Max |
|
Weight |
1,757 lb (797kg) |
|
Envelope Dimensions |
34.62 L x 37.24 W x 26.95 H (inches) 0.879 L x 0.946 W x 0.685 H (meters) |
|
Noise Output |
~72 dB @ 3.3 feet (1 meter) |
|
Seawater Supply to Heat Exchanger |
4.5 GPM (17 LPM) Minimum 6.0 GPM (22.7 LPM) Maximum |
|
Ambient Air Temperature |
32F – 140F (0C – 60C) |
Seakeeper Warranty
To ensure peace of mind, all Seakeeper products come with a multi-year factory warranty
